Siemens Simatic ET 200SP HA, Analog input module 6DL11346JH000PH1 SIMATIC ET 200SP HA, Analog input module, AI 16XTC/8XRTD 2-/3-/4-Wire HA, suitable for Terminal Block H1, M1, Color code CC00, channel diagnostics, 16bit , +/-0.05%, 2-/3-/4-Wire Technical data General informationProduct type designation AI 16 x TC/8xRTD 2-/3-/4-wire HAFirmware version V1.1 ● Possible FW update YesTerminal block usable terminal block type H1, M1, P0 and N0Color code for module-specific color coding plateCC00 Product function● I&M data Yes; I&M0 ... I&M3 Engineering with● STEP 7 TIA Portal configurable/integrated from version V16● STEP 7 configurable/integrated from version V5.6● PCS 7 configurable/integrated from version V9.0● PCS neo configurable/integrated from version V3.0● PROFINET from version GSD/GSD revision GSDML V2.3 Redundancy● Redundancy capabilities Yes; with type TB M1 CiR - Configuration in RUNReparameterization in RUN possible Yes Supply voltageRated value (DC) 24 VAllowable range, lower limit (DC) 19.2 VAllowable range, upper limit (DC ) 28.8 VReverse polarity protection Yes Input currentCurrent consumption (nominal value) 75 mACurrent consumption, max. 100 mA Power dissipationPower dissipation, typ. 1.8 W Address spaceAddress space per module● Address space per module, max. 64 bytes; + 2 bytes for IQ information Analog inputsNumber of analog inputs● for voltage measurement 16● for measurement with resistance/thermoresistance 8● for measurement with thermocouple 16 Permitted input voltage for voltage input (destructivelimit), max.5 VConstant measuring current for resistive transducers, typ. 2 mA

Read more less

Schneider Electric TM5SAI2L Analog input module 2 inputs, +/-10 V / 0...20mA / 4...20mA, 12 bits. Product range: Modicon TM5 - Product or component type: Analog input module - Analog input type: Current 0...20 mA/4...20 mA, differential, Voltage +/- 10 V, differential - Analog input resolution: 12 bits + sign +/- 10 V, 12 bits 0...20 mA/4...20 mA.  Technical data Range compatibility Modicon M258 Modicon LMC058 Product Compatibility Logic controller Motion controller resolution measure 2.441mV, +/- 10V 4.883 µA, 0...20 mA/4...20 mA Color White input impedance >= 20 mOhm voltage ohmic load impedance <= 300 Ohm (current) sampling duration 1 ms, analog input type: all inputs with filtering 300 µs, analog input type: all inputs without filtering measurement error < 0.08% of full scale +/- 10 V +/- 10 V at 25 °C < 0.08% of full scale 0...20 mA/4...20 mA at 25 °C temperature coefficient +/- 0.009 %FS/°C, analog input type: current +/- 0.006 %FS/°C, analog input type: voltage non-linearity < 0.025%FS, analog input type: voltage < 0.05%FS, analog input type: current Type of cables Shielded cable insulation No insulation between channels 500 Vrms AC isolation between channel and bus Diet Internal Rated supply voltage [Us] 24V DC -15...20% Common mode rejection > 70dB local reporting 1 green LED for power 1 red LED for power 2 green LEDs for input status current absorption 2 mA at 5 V DC bus 33 mA at 24 V DC input/output Maximum power dissipation in W 0.81W Marking THERE IS Net weight 0.025 kg

Read more less

Siemens 6ES73317KB020AB0SIMATIC S7-300, analog input module SM 331, electrically isolated, 2 AE, resolution 9/12/14 bit, U/I/Thermocouple/Resistance, alarm, diagnostics, 1 x 20-pole, switch-off/on with active backplane bus

Read more less

Siemens 6ES75317NF000AB0SIMATIC S7-1500, analog input module AI 8xU/I HF, resolution max. 24 bit, accuracy 0.1 %, 8 channels in groups of 1, common mode voltage: 30 V AC/60 V DC, hardware interrupt diagnostics scalable measured values, measuring range adaptation, calibration in RUN included in delivery a power supply element, shield bracket and shield clamp: front connector (screw terminals or push-in) to be ordered separately SIMATIC ET 200MP is a modular, scalable I/O system for universal use in IP20 and offers the same advantages system of the S7-1500. It enables minimum bus cycle times and very fast response times even for large quantity structures. The distributed I/O system is particularly easy to install, wire and commission. Thanks to the scalable structure, the peripheral station can be customized exactly to the needs on site. The wide range of input/output modules ensures the scalable configuration of an ET 200MP station. Numerous digital and analog input and output modules are available. This ensures the possibility of universal use of the system.

Read more less

Siemens 6ES73311KF020AB0SIMATIC S7-300, analog input module SM 331, electrically isolated 8AE, resol. 13 bit U/I/resistor/Pt100, NI100, NI1000, LG-NI1000, PTC/KTY, conversion time 66ms, 1 x 40 poles SIMATIC ET 200M is a modular I/O system that can be used universally for control cabinets in IP20 , which can be used as central I/O on S7-300 as well as in a distributed structure with a PROFINET or PROFIBUS ET 200M interface module. Up to 12 IO modules can be inserted in each station. The standardized structure of all modules significantly simplifies logistics and spare parts management. ET 200M can be used for both standard and safety-oriented applications. Up to 12 multi-channel input/output modules (e.g. 64 digital inputs) and function modules as well as communication processors of the S7-300 can be used as peripheral units (the interface to the process). The ET 200M also supports modules with extended user data, e.g. HART units with auxiliary HART variables. For simple wiring, in addition to the classic connection techniques, the ET 200M features the Fast Connect quick connection technique without the need for stripping the cable.

Read more less

Schneider Electric TM3TM3GTM3 module, 2 temperature inputs and 1 analog output, spring. product range: Modicon TM3 - type of product or component: analog input/output module - range compatibility: Modicon M221, Modicon M241, Modicon M251 - analog input type: current, analogue input range: 0...20 mA, current , analogue input range: 4...20 mA, Ni 100/Ni 1000 temperature probe, analogue input range: - 60...180 °C, Pt 100 temperature probe, analogue input range: - 200...850 °C, Pt 1000 temperature probe, analogue input range: - 200...600 °C, voltage, analogue input range: - 10...10 V, voltage, analogue input range: 0...10 V, thermocouple , analogue input range: - 200...1300°C with thermocouple K, thermocouple, analogue input range: - 200...1300°C with thermocouple N, thermocouple, analogue input range: - 200...400°C with thermocouple T, thermocouple, analogue input range: 0...1760°C with thermocouple R, thermocouple, analogue input range: 0...1760°C with thermocouple S, thermocouple, analogue input range: 0...1820°C with thermocouple B, thermocouple, analogue input range: 0...2315°C with thermocouple C, thermocouple, analogue input range: -200...1000°C with thermocouple J, thermocouple, analogue input range: -200...800 °C with thermocouple E - analog output type: 0...10 V voltage, 0...20 mA current, -10...10 V voltage, 4...20 mA current. Benefits: .. Applications: .. Benefits: Special feature: Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism. A bus expansion connector is used to distribute data and the power supply when assembling the Modicon TM3 expansion modules with logic controllers.... Applications: Learn more about our machine control solutions!..

Read more less

Schneider Electric TM3TM3TM3 module, 2 temperature inputs and 1 analogue output. product range: Modicon TM3 - type of product or component: analog input/output module - range compatibility: Modicon M221, Modicon M241, Modicon M251 - analog input type: current, analog input range: 0...20 mA, current , analogue input range: 4...20 mA, Ni 100/Ni 1000 temperature probe, analogue input range: - 60...180 °C, Pt 100 temperature probe, analogue input range: - 200...850 °C, Pt 1000 temperature probe, analogue input range: - 200...600 °C, voltage, analogue input range: - 10...10 V, voltage, analogue input range: 0...10 V, thermocouple , analogue input range: - 200...1300°C with thermocouple K, thermocouple, analogue input range: - 200...1300°C with thermocouple N, thermocouple, analogue input range: - 200...400°C with thermocouple T, thermocouple, analogue input range: 0...1760°C with thermocouple R, thermocouple, analogue input range: 0...1760°C with thermocouple S, thermocouple, analogue input range: 0...1820°C with thermocouple B, thermocouple, analogue input range: 0...2315°C with thermocouple C, thermocouple, analogue input range: -200...1000°C with thermocouple J, thermocouple, analogue input range: -200... 800°C with thermocouple E - analogue output type: 0...10 V voltage, 0...20 mA current, -10...10 V voltage, 4...20 mA current. Benefits: .. Applications: .. Benefits: Special feature: Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism. A bus expansion connector is used to distribute data and the power supply when assembling the Modicon TM3 expansion modules with logic controllers.... Applications: Learn more about our machine control solutions!..

Read more less

Schneider Electric TM3TI4GTM3 module, 4 temperature inputs, spring. product range: Modicon TM3 - type of product or component: analogue input module - range compatibility: Modicon M221, Modicon M241, Modicon M251 - analogue input type: current, analogue input range: 0...20 mA, current, analogue input range: 4...20 mA, Pt 100 temperature probe, analogue input range: - 200...850 °C, Pt 1000 temperature probe, analogue input range: - 200...600 °C, voltage, analogue input range: - 10...10 V, voltage, analogue input range: 0...10 V, thermocouple, analogue input range: - 200...1300°C with thermocouple K, thermocouple, analogue input range: - 200 ...1300°C with thermocouple N, thermocouple, analogue input range: - 200...400°C with thermocouple T, thermocouple, analogue input range: 0...1760°C with thermocouple R, thermocouple, analogue input range : 0...1760°C with thermocouple S, thermocouple, analogue input range: 0...1820°C with thermocouple B, thermocouple, analogue input range: 0...2315°C with thermocouple C, thermocouple, analogue input range: -200...1000°C with thermocouple J, thermocouple, analogue input range: -200...800°C with thermocouple E. Benefits: .. Applications: .. Benefits: Special feature: Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism. A bus expansion connector is used to distribute data and the power supply when assembling the Modicon TM3 expansion modules with logic controllers.... Applications: Learn more about our machine control solutions!..

Read more less

Siemens 6ES73325HF000AB0SIMATIC S7-300, analog output module SM 332, electrically isolated, 8 AO, diagnostic U/I resolution 11/12 bit, 40-pin, extraction and insertion possible with active backplane bus

Read more less

Schneider Electric TM3AQ4GTM3 module, 4 analogue outputs, spring. product range: Modicon TM3 - type of product or component: analog output module - range compatibility: Modicon M221, Modicon M241, Modicon M251 - analog output type: 0...10 V voltage, 0...20 mA current, -10 ...10 V voltage, 4...20 mA current. Benefits: .. Applications: .. Benefits: Special feature: Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism. A bus expansion connector is used to distribute data and the power supply when assembling the Modicon TM3 expansion modules with logic controllers.... Applications: Learn more about our machine control solutions!..

Read more less

Siemens 6ES72324HB320XB0SIMATIC S7-1200, analog output module, SM 1232, 2 AO, +/-10 V, 14 bit resolution, or 0-20mA/4-20mA, 13 bit resolution SIMATIC S7-1200 Basic Controller - Flexibility guaranteed by various communication options. With the input/output modules you can customize the configuration of your SIMATIC S7-1200 (except CPU 1211C) according to your specific needs. Furthermore, a series of digital or analog input and output modules and mixed modules are available, also in fail-safe variants. With these comprehensive construction options, you can save space in the control cabinet and optimize hardware costs.

Read more less

Siemens 6ES75317QD000AB0SIMATIC S7-1500, analog input module AI 4xU/I/RTD/TC ST, resolution 16 bit, accuracy 0.3 %, 4 channels in groups of 4 , 2 channels for RTD measurement, common mode voltage 10V hardware interrupt diagnostics delivery including push-in front connector, power supply element, shield bracket, and shield clamp SIMATIC ET 200MP is a modular and scalable I/O system for universal use in IP20 and offers the same system advantages as the S7-1500. It enables minimum bus cycle times and very fast response times even for large quantity structures. The distributed I/O system is particularly easy to install, wire and commission. Thanks to the scalable structure, the peripheral station can be customized exactly to the needs on site. The wide range of input/output modules ensures the scalable configuration of an ET 200MP station. Numerous digital and analog input and output modules are available. This ensures the possibility of universal use of the system.

Read more less

Siemens 6ES75325HD000AB0SIMATIC S7-1500, AQ 4xU/I ST analog output module, 16 bit resolution, accuracy 0.3%. 4 channels in groups of 4, substitute value diagnostics the unit supports the safe disconnection of load groups up to SILCL1 according to EN 62061:2005 + A2:2015, and category 2 / PL c according to EN ISO 13849-1:2015. delivery including a power supply element, shield bracket and shield clamp: front connector (screw terminals or push-in) to be ordered separately SIMATIC ET 200MP is a modular, scalable I/O system for universal use in IP20 and offers the same system advantages as the S7-1500. It enables minimum bus cycle times and very fast response times even for large quantity structures. The distributed I/O system is particularly easy to install, wire and commission. Thanks to the scalable structure, the peripheral station can be customized exactly to the needs on site. The wide range of input/output modules ensures the scalable configuration of an ET 200MP station. Numerous digital and analog input and output modules are available. This ensures the possibility of universal use of the system.

Read more less

Siemens 6ES75325NB000AB0SIMATIC S7-1500, analog output module AQ 2x U/I ST, resolution 16 bit, accuracy 0.3%. 2 channels in groups of 2 diagnostics substitute value the unit supports the safe disconnection of load groups up to SILCL1 according to EN 62061:2005 + A2:2015, and category 2 / PL c according to EN ISO 13849-1:2015. delivery including a push-in front connector, power supply element, shield bracket and shield clamp SIMATIC ET 200MP is a modular, scalable I/O system for universal use in IP20 and offers the same system advantages as the S7- 1500. It enables minimum bus cycle times and very fast response times even for large quantity structures. The distributed I/O system is particularly easy to install, wire and commission. Thanks to the scalable structure, the peripheral station can be customized exactly to the needs on site. The wide range of input/output modules ensures the scalable configuration of an ET 200MP station. Numerous digital and analog input and output modules are available. This ensures the possibility of universal use of the system.

Read more less

Siemens 6ED10551MM000BA2LOGO! AM2 AQ expansion module, SV: DC 24V, 2 AA, 0-10 V, 0/4-20mA for LOGO! 8 The LOGO! expansion modules allow you to create a LOGO! very personalized. A LOGO! basic device 8 can be expanded up to max. 24 digital inputs, 20 digital outputs, 8 analog inputs and 8 analog outputs. For this purpose, ten different expansion modules are available which allow the addition of digital or analog inputs and outputs with different input voltages.

Read more less

Siemens 6ES72315QF320XB0SIMATIC S7-1200, analog input module, SM 1231 TC, 8 AI thermocouples SIMATIC S7-1200 Basic Controller - Flexibility guaranteed by various communication options. With the input/output modules you can customize the configuration of your SIMATIC S7-1200 (except CPU 1211C) according to your specific needs. Furthermore, a series of digital or analog input and output modules and mixed modules are available, also in fail-safe variants. With these comprehensive construction options, you can save space in the control cabinet and optimize hardware costs.

Read more less

Siemens 6ES75317NF100AB0SIMATIC S7-1500, AI 8xU/I HS analog input module, 16-bit resolution, 0.3 % accuracy, 8 channels in groups of 8, common mode voltage 10V process interrupt diagnostics 8 channels in 0.0625 ms oversampling delivery including a power supply element, shield bracket and shield clamp: front connector (screw terminals or push-in) to be ordered separately SIMATIC ET 200MP is a system modular and scalable I/O module for universal use in IP20 and offers the same system advantages as the S7-1500. It enables minimum bus cycle times and very fast response times even for large quantity structures. The distributed I/O system is particularly easy to install, wire and commission. Thanks to the scalable structure, the peripheral station can be customized exactly to the needs on site. The wide range of input/output modules ensures the scalable configuration of an ET 200MP station. Numerous digital and analog input and output modules are available. This ensures the possibility of universal use of the system.

Read more less

Siemens 6ES72344HE320XB0SIMATIC S7-1200, SM 1234 analog I/O, 4 AI/2 AO, +/-10 V, 14 bit resolution or 0 (4)-20mA, 13 bit resolution SIMATIC S7-1200 Basic Controller - Flexibility guaranteed by various communication options. With the input/output modules you can customize the configuration of your SIMATIC S7-1200 (except CPU 1211C) according to your specific needs. Furthermore, a series of digital or analog input and output modules and mixed modules are available, also in fail-safe variants. With these comprehensive construction options, you can save space in the control cabinet and optimize hardware costs.

Read more less

Siemens 6ED10551MA000BA2LOGO! AM2 Expansion module, SV/: DC 12/24V, 2 AE, 0-10V or 0/4-20mA for LOGO! 8 The LOGO! expansion modules allow you to create a LOGO! very personalized. A LOGO! basic device 8 can be expanded up to max. 24 digital inputs, 20 digital outputs, 8 analog inputs and 8 analog outputs. For this purpose, ten different expansion modules are available which allow the addition of digital or analog inputs and outputs with different input voltages.

Read more less

Siemens 6ES72315ND320XB0SIMATIC S7-1200, analog input module, SM 1231, 4 AI, +/-10 V, +/-5 V, +/-2.5V, + /-1.25 or 0-20mA/4-20mA, 15 bits + sign bit SIMATIC S7-1200 Basic Controller - Flexibility guaranteed by various communication options. With the input/output modules you can customize the configuration of your SIMATIC S7-1200 (except CPU 1211C) according to your specific needs. Furthermore, a series of digital or analog input and output modules and mixed modules are available, also in fail-safe variants. With these comprehensive construction options, you can save space in the control cabinet and optimize hardware costs.

Read more less

Siemens 6ES72314HA300XB0SIMATIC S7-1200, analog input module, SB 1231, 1 AI, +/- DC 10 V (12-bit resolution) or 0-20mA SIMATIC S7-1200 Basic Controller - Flexibility guaranteed by various communication options. If you need to expand your SIMATIC S7-1200 CPU with only a few inputs or outputs, Signal Boards are a valid alternative to input and output modules. The Signal Boards are inserted directly on the front of the controller (also possible with CPU 1211C) and are available as analogue or digital inputs and outputs and mixed modules. A Communication Board with RS 485 interface is also available. The Signal Boards also allow subsequent expansion of the configuration without requiring additional space in the control cabinet.

Read more less

Siemens 6ES72315PF320XB0SIMATIC S7-1200, analog input module, SM 1231 RTD, 8x AI RTD modules SIMATIC S7-1200 Basic Controller - Flexibility guaranteed by various communication options. With the input/output modules you can customize the configuration of yourSIMATIC S7-1200 (except CPU 1211C) according to your specific needs. Furthermore, a series of digital or analog input and output modules and mixed modules are available, also in fail-safe variants. With these comprehensive construction options, you can save space in the control cabinet and optimize hardware costs.

Read more less

Siemens 6ES72315QD320XB0SIMATIC S7-1200, analog input module, SM 1231 TC, 4 AI thermocouples SIMATIC S7-1200 Basic Controller - Flexibility guaranteed by various communication options. With the input/output modules you can customize the configuration of your SIMATIC S7-1200 (except CPU 1211C) according to your specific needs. Furthermore, a series of digital or analog input and output modules and mixed modules are available, also in fail-safe variants. With these comprehensive construction options, you can save space in the control cabinet and optimize hardware costs.

Read more less

Schneider Electric TM3AM6GTM3 module, 4 analog inputs and 2 analog outputs, spring. product range: Modicon TM3 - type of product or component: analog input/output module - range compatibility: Modicon M221, Modicon M241, Modicon M251 - analog input type: current, analogue input range: 0...20 mA, current , analogue input range: 4...20 mA, voltage, analogue input range: - 10...10 V, voltage, analogue input range: 0...10 V - analogue output type: 0...10 V voltage , 0...20 mA current, -10...10 V voltage, 4...20 mA current. Benefits: .. Applications: .. Benefits: Special feature: Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism. A bus expansion connector is used to distribute data and the power supply when assembling the Modicon TM3 expansion modules with logic controllers.... Applications: Learn more about our machine control solutions!..
