CONTROL RELAY

Finder 345170240010 (A): 6 Number of contacts: 1 CO Contact material: AgNi Electrical connection: push-in fitting Power supply: DC Volt DC: 24 V. non-polarised monostable Protection category: RT II Accessories: Socket S.93

Read more less

Finder mini relay for printed circuit and plug-in 16A 406190120000 The Type 40.61 mini relay is a device for mounting on PCB or 95 series sockets. Features: 1 Exchange 5.0 mm pitch Terminal length 3.5 mm for PCB mounting Terminal length 5.3 mm for plug-in relay DC coil (650 mW or 500 mW) Compliance with the glow wire test according to EN 60335-1 Protection category:– RT II – flux-proof (Standard)– RT III – washable (Special version)

Read more less

Omron CGL1255S4-186737Single probe electrode, l=500 mm, diam. 6 mm, in AISI 304, 3/8 gas threaded connection

Read more less

SIEMENS SITOP SEL1200 SELECTIVITY MODULE 8 *10A 6EP4438-7FB00-3DX0 SITOP SEL1200 8-channel selective module switching characteristic input: DC 24 V/60 A output: DC 24 V/8 x 10 A settable threshold value 2 ... 10 A with monitoring interface. General information: Inputshape of the electrical network Regulated DC voltagesupply voltage with DC rated value 24 Vinput voltage with DC 20.4 ... 30 Voverloadability for overvoltage 35 Vinput current with nominal value of theinput voltage 24 V rated value 60 A Outputshape of the voltage curve at the output Regulated DC voltageformula for output voltage Ue - approx. 0.2 Voverall relative voltage tolerance known Corresponding to the input supply voltage number of outputs 8output current up to 60 °C for each output rated value 10 A; +60 ... +70 °C: Derating 2%/K settable trip value for current-dependent overload release current 2 ... 10 Atype of trip value setting Via potentiometerproduct characteristic parallel connection of outputs Yestype of activation of the outputs Activation of all outputs when the operating value is reached of thesupply voltage > 20 V, delay time of 25 ms, 200 ms, 500ms or adjustable via DIP switch for "load-optimized" sequential switching on Efficiencyefficiency [%] 98 %power dissipation [W] at nominal value of theoutput voltage at nominal value of the output current typ. 18 W Switch-off characteristic for each outputswitching characteristic● of overcurrent shutdown IA > 2.0 x set value, switch-off after approx. 30 ms, IA > 1.8 x setvalue, switches off after approx. 0.1 s, IA > 1.5 x set value,switch-off after approx. 1 s, IA > 1.0 x set value, switches off after approx. 5 s● of immediate switch-off IA > set value and Ue 15 V) Protection and monitoring performing protection on the 16 A input for each output (not accessible) performing the display for normal operation Tricolor LED for each output: green LED for "Output activated", yellow LED for "Output manually deactivated", red LED for "Output deactivated due to overcurrent" execution of the switching contact for   signaling function.                                   Status signal output or floating cumulative signaling contact (pause/pulse signal selectable from theSimaticfunction block).

Read more less

700-HR52TU24 ROCKWELL AUTOMATION Relè temporizzato Rockwell Automation serie/modello TUBE BASE DIAL TIMING RELAY

Read more less

Lovato TMM1 Lovato Multifunction Timer– Modular versions for switchboards also suitable for panel bottom mounting.– Flush-mounted versions.– Programmable version with NFC and APP technology.– Wide range of functions and scales.– High precision and repeatability of times. Functions: – Enable input– Selectable functions:– Delayed relay activation;– Intermittent with start of pause;– Intermittent with start of work;– Relay activation when a contact closes and delayed de-energization when a contact opens;– Timed activation of the relay when a contact closes;– Timed activation of the relay when a contact opens;– Delayed activation of the relay when a contact closes and deferred deactivation when it opens;– Step relay when a contact closes;– Pulse generator– Adjustable delay time on the front: 10 – 100%– Green LED to indicate power presence– Red LED for relay status indication, flashing during the delay and lit when the relay is energized– Modular container DIN 43880 (1 module), suitable for fixing on 35mm omega profile or screw fixing– Degree of protection: IP40 on the front (if mounted in a container and/or electrical panel with IP40), IP20 terminals.

Read more less

FINDER MODULAR MULTIFUNCTION TIMER 12/240V 16A 800102400000 Multifunction & multivoltage modular timer Number of contacts: 1 CO Contact material: AgNi (A): 16 Power supply: AC/DC Volt AC: 240 V. Volt DC: 240 V. suitable for front mounting: no with plug-in base: no remote control possible: no only suitable for remote control: no flashing function with initial pause, fixed time: no flashing function with initial pulse, fixed time: no with semiconductor output: yes ON-delayed function: yes pass-through function with ON delay: yes star/delta function: no time range: from 0.1 to 86400 s. OFF-delayed function: yes Pass-through function with OFF-delay: yes Electrical connection: screw connection suitable for mounting on top rail: yes Degree of protection: IP20. Type 80.01T modular timer, multivoltage and multifunction, with screw terminals. Functions: AI: On delay DI: Interval SW: Symmetrical flasher start ON BE: Switch-off delay with control signal CE: On and off delay with control signal DE: Instantaneous interval with command signal Features: Compliant with standards EN 45545-2 +A1:2016 (protection against fire and smoke), EN 61373 (resistance to shock and vibration, category 1, class B), EN 50155 (resistance to temperature and humidity, class T1) Width 17.5 mm Six time scales from 0.1 s to 24 h High input/output isolation “Blade + cross” casing with regulator, rotary function selectors and time scales, 35 mm bar hook which can be operated with both slotted and Phillips screwdrivers New multivoltage versions with “PWM clever” technology Mounting on 35 mm rail (EN 60715) ApplicationsDoor controlInfotainment message panelsManeuvering desks

Read more less

Finder industrial mini relay 16A 466180240040 The type 46.61 of Finder is an industrial power mini relay that allows mounting on a socket or direct connection via Faston. Features: 1 exchange 16 A Plug-in terminals/Faston 187 Available with: lockable test button, mechanical indicator and LED 8 mm, 6 kV (1.2/50 μs) insulation between coil and contacts Cadmium-free contacts Series 99 EMC signaling and protection modules and 86.30 type timer modules Alternative mounting adapters available Technical data: Type of electrical connection: ConnectorComplete with socket: noWith removable terminals: no Rated control voltage Us 50Hz AC: 24...24 VRated control voltage Us 60Hz AC: 24...24 VType voltage for the drive: AC Drive polarity: Non-polarizedSwitching type: Monostable Number of NC contacts: 0Number of NO contacts: 0Number of changeover contacts: 1Type of changeover contacts: Single contactWith forced actuation contacts: no Rated current: 16 A

Read more less

Finder Industrial mini relay 8 - 16 A 466182300040 Mini industrial relay, 1 exchange 16A, with plug-in/Faston 187 terminals. Equipped with AC or DC coil. Available with: lockable test button and mechanical and LED indicator. With Cadmium-free contacts. European patent Technical description: Mini industrial relay, Plug-in terminals/Faston terminals, 1 contact, CO, 16 A, AgNi, AC coil, 230 V, operation from 184 to 253 V, power nominal 1.2 VA, resistance 28000 Ω, consumption 5 mA, holding voltage 184 V, release voltage 46 V, variant: Test button + mechanical indicator, ambient temperature -40 to +70 °C

Read more less

Finder Industrial mini relay 8 - 16 A 466180120040 Mini industrial relay, 1 exchange 16A, with plug-in/Faston 187 terminals. Equipped with AC or DC coil. Available with: lockable test button and mechanical and LED indicator. With Cadmium-free contacts. European patent. Technical description: Mini industrial relay, Plug-in terminals/Faston terminals, 1 contact, CO, 16 A, AgNi, AC coil, 12 V, operation from 9.6 to 13.2 V, power nominal 1.2 VA, resistance 80 Ω, consumption 90 mA, holding voltage 9.6 V, release voltage 2.4 V, variant: Test button + mechanical indicator, ambient temperature -40 to +70 °C

Read more less

FINDER TYPE 40.52 - MINI RELAY FOR PRINTED CIRCUIT 2 changeover contacts for printed circuit and plug-in coil 12V DC contact capacity 8A 405290120000 The Type 40.52 mini relay is a Series 95 socket-mounted printed circuit relay. Equipped with 2 8 A exchanges on printed circuit, 5.0 mm pitch, it is a versatile device suitable for multiple applications such as control panels, control and distribution panels, electronic cards, door and gate opening and much more. Features: Terminal length 3.5 mm for PCB mounting Terminal length 5.3 mm for plug-in relay DC coil (650 mW or 500 mW) Variant with Cadmium-free contacts 8 mm, 6 kV (1.2/50µs) insulation between coil and contacts Compliance with the Glowe wire test according to EN 60335-1 95 series sockets for printed circuit, or for mounting on 35 mm rail (EN 60715) with Push-in, screw or spring terminals Series 99 EMC signaling and protection modules and 86.30 type timer modules Protection category:• RT II – flux proof (Standard)• RT III – washable (Special version) ApplicationsElectromedical, dentistryControl panelsControl panels, distributionToysAutomation of awnings, shutters, shuttersOpening doors and gates Electronic cardsVending machines

Read more less

Finder Mini PCB relay PCB/plug 405280240000 The Type 40.52 mini relay is a Series 95 socket-mounted printed circuit relay. Equipped with 2 8 A exchanges on printed circuit, 5.0 mm pitch, it is a versatile device suitable for multiple applications such as control panels, control and distribution panels, electronic cards, door and gate opening and much more. FEATURES Number of exchange contacts: 2Rated current: 8 ARated control voltage Us 50Hz AC: 24...24 VWith forced actuation contacts: noType of electrical connection: PCB connection (printed circuit board)With removable terminals: noRated control voltage Us 60Hz AC: 24...24 VType of voltage for the drive: ACPolarity of the drive: Non-polarisedType of switching: MonostableNumber of NC contacts: 0Number of NO contacts: 0Type of switching contacts: Single contactComplete with socket: noWidth: 12.4 mmHeight: 25 mmDepth: 29 mm ApplicationsElectromedical, dentistryControl panelsControl panels, distributionToysAutomation of awnings, shutters, roller shuttersOpening doors and gatesElectronic cardsAutomatic dispensers

Read more less
