DATACOM

Siemens Industrial Ethernet FC TP Standard Cable  6XV18402AH10  Industrial Ethernet FC TP Standard Cable, GP 2x2 (PROFINET type A), TP installation cable for connection to IE FC RJ45 2x2, universally applicable, 4-core, shielded CAT 5E, sold by the meter , supply unit max. 4000m, min. orderable quantity 20m. Suitability for use Standard cable with rigid conductors for quick assembly cable designation 2YY (ST) CY 2x2x0.64/1.5-100 GN SF/UTPelectrical data attenuation ratio per length ● at 10 MHz / max. 0.052 dB/m● at 100 MHz / max. 0.195 dB/m Characteristic impedance ● at 1 MHz ... 100 MHz 100 Ωrelative symmetrical tolerance ● of the characteristic impedance at 1 MHz ... 100 MHz 15 %paracrosstalk attenuation per length ● at 1 MHz ... 100 MHz 0.5 dB/mcoupling resistance per length / at 10 MHz 10 mΩ/mloop resistance by length / max. 115 mΩ/m Operating voltage ● rms value 80 V% NVP value 69 %mechanical data number of electrical conductors 4shield design Steel plated foil overlapping aluminium, wrapped in a shielding braid made of tinned copper wiresexecution of the electrical connection / FastConnect Yes Diameter of conductor ● of the AWG22 conductors 0.64 mmouter diameter ● of the internal conductor 0.64 mm● of the insulation of the conductors 1.5 mm● of the inner cable sheath 3.9 mm● of the cable sheath 6.5 mmsymmetrical tolerance of the outer diameter / of the cable sheath 0.2 mm Material ● of the conductor insulation Polyethylene (PE)● of the inner cable sheath PVC● of the cable sheath PVCcolor ● data wire insulation white/yellow/blue/orange● cable sheath green Radius of curvature ● for a single curvature / min. permissible 19.5 mm● for repeated bending / min. permissible 49 mmpull load / max. 150 Nweight per length 61 kg/km

Read more less

Siemens Scalance XB008 unmanaged Industrial Ethernet Switch  6GK50080BA101AB2 SCALANCE XB008 unmanaged Industrial Ethernet Switch for 10/100 Mbit/s; for the configuration of small star structures and linear structures; LED diagnostics, IP20, AC/DC 24V voltage supply, with 8x 10/100 Mbit/s Twisted Pair Ports with RJ45 sockets; manual available as download  Product type designation SCALANCE XB008 baud rate baud rate 10 Mbit/s, 100 Mbit/s interfaces / for communication / max. configuration with modular devices number of electrical doors / max. 8 interfaces / for communication / integr. number of electrical connections ● for network components or terminal equipment 8; RJ45 number of SC ports at 100 Mbit/s ● for multimode 0 interfaces / others number of electrical connections ● for voltage supply 1 execution of the electrical connection ● for voltage supply Terminal block 3 poles supply voltage, current absorbed, power dissipated type of voltage / 1 / of the DC supply voltage ● supply voltage / 1 / rated value 24 V ● power loss [W] / 1 / rated value 2.88 W ● supply voltage / 1 / rated value 19.2 ... 28.8 V ● current absorbed / 1 / max. 0.12 A ● design of the electrical connection / 1 / for voltage supply 3-pole terminal block o● integral part of the product / 1 / protection on the power input Yes ● design of the protection / 1 / on the input for supply voltage 0.6 A / 60 V voltage type / 2 / of the supply voltage AC ● supply voltage / 2 / nominal value 19.2 ... 28.8 V environmental conditions ambient temperature ● during operation -10 ... +60 °C ● during storage -40 ... + 80 °C ● during transport -40 ... +80 °C relative humidity ● at 25 °C / without condensation / during operation / max. 95 % IP protection degree IP20 construction form, dimensions and weights Box construction form width 45 mm height 100 mmheight 100 mm depth 87 mm net weight 0.18 kg

Read more less

SIEMENS SIMATIC NET SCALANCE XB005 6GK50050BA001AB2 SCALANCE XB005 unmanaged Industrial Ethernet Switch for 10/100 Mbit/s; for the configuration of small star structures and linear structures; LED diagnostics, IP20, AC/DC 24V voltage supply, with 5x 10/100 Mbit/s Twisted Pair Ports with RJ45 sockets. General information: Transmission ratetransmission rate 10 Mbit/s, 100 Mbit/s Interfaces / for communication / max. configuration with modular devicesnumber of electrical doors / max. 5interfaces / for communication / integr.number of electrical connections● for network components or terminal equipment 5; RJ45number of SC ports at 100 Mbit/s● for multimode 0 interfaces / othersnumber of electrical connections● for voltage supply 1execution of the electrical connection● for voltage supply Terminal block 3 poly Supply voltage, current consumption, power dissipationvoltage type / 1 / of the DC supply voltage● supply voltage / 1 / nominal value 24 V● power dissipation [W] / 1 / nominal value 1.68 W● supply voltage / 1 / nominal value 19.2 ... 28.8 V● current consumption / 1 / max. 0.07 A● execution of the electrical connection / 1 / for voltage supply3-pole terminal block● integral part of the product / 1 / input protectionpower supply Yes● implementation of protection / 1 / on the input forsupply voltage 0.6 A / 60 Vtype of voltage / 2 / of the supply voltage AC● voltage power supply / 2 / nominal value 19.2 ... 28.8 V Environmental conditionsambient temperature● during operation -10 ... +60 °C● during storage -40 ... + 80 °C● during transport -40 ... +80 °C Relative humidity● at 25 °C / non-condensing / during operation / max. 95 %IP protection degree IP20construction form, dimensions and weightsBox construction formwidth 45 mmheight 100 mm

Read more less

SIEMENS SCALANCE XC208 6GK52080BA002AC2 Manageable Layer 2 IE Switch; IEC 62443-4-2 certified; 8x 10/100 Mbit/s RJ45 ports; 1x console port; Diagnostic LEDs; redundant voltage supply; temperature range -40 °C...+70 °C; mounting: DIN rail/S7 profile/wall redundancy functions Office Features (RSTP, VLAN,...); Ethernet/IP compliant PROFINET IO device C-PLUG slot. General information Product type designation: SCALANCE XC208   Transmission speedTransmission speed 10 Mbit/s, 100 Mbit/s Interfaces / for communication / max. configuration with modular devicesNumber of electrical doors / max. 8 Interfaces / for communication / integration Number of electrical connections● for network components or terminal equipment 8; RJ45number of RJ45 ports at 10/100 Mbit/s / integrated● with retention collar 8 Interfaces / others number of electrical connections● for control console 1● for signaling contact 1● for power supply 1execution of the electrical connection● for control console RJ11 ● for power supply 4-pin terminal blockdesign of removable storage medium● C-PLUG Yes Signal inputs/outputs operational voltage / of the signaling contacts● with DC / rated value 24 Voperating current / of the signaling contacts● with DC / max. 0.1 A Supply voltage, absorbed current, dissipated power integral part of the product / connection for redundant voltage supply Yesvoltage type / 1 / of the DC supply voltage● supply voltage / 1 / nominal value 24 V● power loss [ W] / 1 / nominal value 4.2 W● current consumption / 1 / with nominal value of the supply voltage / max.0.175 A● supply voltage / 1 / nominal value 9.6 ... 31.2 V● current consumption / 1 / max. 0.35 A● execution of the electrical connection / 1 / for voltage supply 4-pole terminal block● integral part of the product / 1 / protection on the power input Yes

Read more less

SIEMENS SIMATIC NET SCALANCE XB208 (DC 24 V) 6GK52080BA002AB2 SCALANCE XB208 manageable Layer 2 IE Switch 8x 10/100 Mbit/s RJ45 ports 1x console port; Diagnostics LED IEC 62443-4-2 certified redundant voltage supply; temp. range 0°C ... +60°C; mounting on profile rail; Default PROFINET. General information product type designation SCALANCE XB208transmission rate 10 Mbit/s, 100 Mbit/snumber of ports / max. 8 interfaces / for communication / configuration max. with modular devicesnumber of electrical doors / max. 8interfaces / for communication / integr. number of electrical connections● for network components or terminal equipment 8; RJ45 Interfaces / others number of electrical connections● for control console 1● for management purposes 1● for power supply 1 execution of the electrical connection● for console control RJ11● for management purposes RJ45 Supply voltage, absorbed current, dissipated power  integral part of the product / connection for redundant voltage supply Yesvoltage type / 1 / of the supply voltage DC● supply voltage / 1 / nominal value 24 V● supply voltage / 1 / nominal value 19.2 ... 28.8 V● current consumption / 1 / max. 0.17 A● execution of the electrical connection / 1 / forvoltage supply6-pole terminal block● integral part of the product / 1 / protection on the power input Yes Standards, specifications, approvals standard● for FM FM3611: Class 1, Division 2, Group A, B, C, D / T4, CL.1, Zone 2, GP. IIC, T4,FM19US0167X● for interference emission EN 61000-6-4 (Class A)● for interference immunity EN 61000-6-2IT safety for industrial automation systems / according to IEC 62443-4-2:2019 YesMTBF 84 a reference code● according to IEC 81346-2:2009 KF● according to IEC 81346-2:2019 KFE Standards, specifications, approvals / CE certificate of suitability / CE marking Yes certificate of suitability / RoHS compliance Yes; Directive 2011/65/EU

Read more less
