SIEMENS SIMATIC NET SCALANCE XB005, 6GK500-50BA0-01AB2
SCALANCE XB005 unmanaged Industrial Ethernet Switch for 10/100 Mbit/s; for the configuration of small star and linear structures; LED diagnostics, IP20, AC/DC 24V power supply, with 5x 10/100 Mbit/s Twisted Pair Ports with RJ45 connectors.
General Information:
Transmission speedtransmission speed 10 Mbit/s, 100 Mbit/s
Interfaces / for communication / max. configuration with modular devicesnumber of electrical ports / max. 5interfaces / for communication / integratednumber of electrical connections● for network components or terminal equipment 5; RJ45number of SC ports at 100 Mbit/s● for multimode 0
interfaces / othersnumber of electrical connections● for power supply 1execution of electrical connection● for power supply Terminal block with 3 poles
Power supply voltage, current consumption, power dissipatedtype of voltage / 1 / of the DC power supply● power supply voltage / 1 / nominal value 24 V● power dissipated [W] / 1 / nominal value 1.68 W● power supply voltage / 1 / nominal value 19.2 ... 28.8 V● current consumption / 1 / max. 0.07 A● execution of electrical connection / 1 / forpower supplyTerminal block with 3 poles● integral part of the product / 1 / protection on the inputof power supply Yes● execution of protection / 1 / on the input forpower supply voltage 0.6 A / 60 Vtype of voltage / 2 / of the AC power supply● power supply voltage / 2 / nominal value 19.2 ... 28.8 V
Environmental conditionsambient temperature● during operation -10 ... +60 °C● during storage -40 ... +80 °C● during transport -40 ... +80 °C
Relative humidity● at 25 °C / no condensation / during operation / max. 95 %degree of protection IP IP20construction form, dimensions, and weightsconstruction form Boxwidth 45 mmheight 100 mm
