SIEMENS LOGIC MODULES

Siemens LOGO! 24CE 6ED1052-1CC08-0BA2 LOGO! 24CE, logic module, display PS/I/O: 24V/24V/24V trans., 8DI (4AI)/4DO,400 block memory, modularly expandable, integrated Ethernet Web Server,data logs, customized web pages, standard microSD card for LOGO! SoftComfort from V8.4, possibility of executing previous connection projectsCloud, MQTT in all LOGO! basic devices 8.4 DisplayWith display YesMounting typeMounting on 35 mm profile rail, width equal to 4 overall dimensionsSupply voltageNominal value (DC)● DC 24 V YesPermissible range, lower limit (DC) 20.4 VPermissible range, upper limit (DC) 28.8 VNowSwitch clocks● Number 400; Max. 400, depending on the function● Power reserve 480 hoursDigital inputsNumber of inputs 8; of which 4 can be used as analogue (0 ... 10 V)Digital outputsNumber of outputs 4; transistorShort circuit protection Yes; electric (1 A)Output current● for signal "1" permissible range for 0 ... 55 °C, max. 0.3AEMCRadio interference emission according to EN 55 011● Limit value class B, for use in zonesresidentialYes; Radio interference suppression according to EN 55011, limit value class BStandards, approvals, certificatesCE Mark YesCSA approval No; equipped with UL certificationUL Listed YesFM approval Yesdeveloped according to IEC 61131 Yesaccording to VDE 0631 YesNaval approval Yes; in preparationEnvironmental conditionsAmbient temperature during operation● min.-20 °C; without condensation● max. 55°CAmbient temperature for storage/transport● min.-40 °C● max. 70°CInvia commentiRiquadri lateraliCronologiaSalvate

Read more less

Siemens 6ED10522MD080BA1LOGO! 12/24RCEO, logic module, PS/I/O: 12/DC 24 V/relay, 8 DI (4 AI)/4 DO, without display, 400 block memory, Ethernet modularity and expandability, integrated Web Server, data log , customized web pages, standard microSD card for LOGO! SOFT Comfort from V8.3, previous projects executable, cloud connection in all LOGO! basic devices 8.3 The LOGO! basic devices 8 with 8 digital inputs and 4 digital outputs and their reduced installation width of only 72 mm, have many well-known functions (current impulse relay, staircase light automation, auxiliary contactor, time relay, etc.) already integrated and freely combinable with each other. The control programs are easily created and simulated on a PC. The respective integrated Ethernet interface allows communication with up to nine LOGO! modules. 8 or SIMATIC S7 systems. With the Web Server, also integrated, the connected users can be monitored and controlled via WLAN or Internet. The user himself can configure web pages, even if he has no knowledge of HTML. Using additional modules, GSM or GPS communication can be implemented as well as integration into a building control system. The LOGO! basic modules 8 are available with and without display for different input voltages as well as with transistor or relay outputs (up to 10 A nominal). Expandable with additional modules up to 24 DI / 20 DQ (8 AI / 8 AQ). Integrated cloud communication. LOGO! 8 can also be expanded with an external Text Display for significant messages in plain text. The backlight color is selectable for optical highlights. Different LOGOs are also available! Power Module for power supply.

Read more less

Siemens 6ED10522CC080BA1LOGO! 24CEo, logic module, without display, PS/I/O: 24V/24V/24V trans., 8DI (4AI)/4DO, 400 block memory, modularly expandable, Ethernet, integrated web server, data log, custom web pages, standard microSD card for LOGO! SOFT Comfort from V8.3, previous executable projects, cloud connection in all LOGO! basic devices 8.3 The LOGO! basic devices 8 with 8 digital inputs and 4 digital outputs and their reduced installation width of only 72 mm, have many well-known functions (current impulse relay, staircase light automation, auxiliary contactor, time relay, etc.) already integrated and freely combinable with each other. The control programs are easily created and simulated on a PC. The respective integrated Ethernet interface allows communication with up to nine LOGO! modules. 8 or SIMATIC S7 systems. With the Web Server, also integrated, the connected users can be monitored and controlled via WLAN or Internet. The user himself can configure web pages, even if he has no knowledge of HTML. Using additional modules, GSM or GPS communication can be implemented as well as integration into a building control system. The LOGO! basic modules 8 are available with and without display for different input voltages as well as with transistor or relay outputs (up to 10 A nominal). Expandable with additional modules up to 24 DI / 20 DQ (8 AI / 8 AQ). Integrated cloud communication. LOGO! 8 can also be expanded with an external Text Display for significant messages in plain text. The backlight color is selectable for optical highlights. Different LOGOs are also available! Power Module for power supply.

Read more less

Siemens 6ED10522HB080BA1LOGO! 24RCEO (AC), logic module, PS/I/O: DC 24V/AC 24V/relay, 8 DI/4 DO, without display, 400 block memory, Ethernet modularity and expandability, integrated Web Server, data log, web pages custom, standard microSD card for LOGO! SOFT Comfort from V8.3, previous projects executable, cloud connection in all LOGO! basic devices 8.3 The LOGO! basic devices 8 with 8 digital inputs and 4 digital outputs and their reduced installation width of only 72 mm, have many well-known functions (current impulse relay, staircase light automation, auxiliary contactor, time relay, etc.) already integrated and freely combinable with each other. The control programs are easily created and simulated on a PC. The respective integrated Ethernet interface enables communication with up to nine LOGO! modules. 8 or SIMATIC S7 systems. With the Web Server, also integrated, the connected users can be monitored and controlled via WLAN or Internet. The user himself can configure web pages, even if he has no knowledge of HTML. Using additional modules, GSM or GPS communication can be implemented as well as integration into a building control system. The LOGO! basic modules 8 are available with and without display for different input voltages as well as with transistor or relay outputs (up to 10 A nominal). Expandable with additional modules up to 24 DI / 20 DQ (8 AI / 8 AQ). Integrated cloud communication. LOGO! 8 can also be expanded with an external Text Display for significant messages in plain text. The backlight color is selectable for optical highlights. Different LOGOs are also available! Power Module for power supply.

Read more less

Siemens LOGO! 24CE 6ED10521CC080BA1 This product has been replaced by a new version: 6ED1052-1CC08-0BA2 | Siemens LOGO! 24CE – DMSTECHMART  LOGO! 24CE, logic module, display PS/I/O: 24V/24V/24V trans., 8DI (4AI)/4DO, 400 block memory, modularity and expandability Ethernet Embedded Web Server, data log, custom web pages, standard microSD card for LOGO! Soft Comfort as of V8.3, previous projects executable, cloud connection in all LOGO! basic devices 8.3 DisplayWith display YesMounting typeMounting on 35 mm standard rail, width equal to 4 dimension unitsSupply voltageNominal value ( DC)● DC 24 V YesPermissible range, lower limit (DC) 20.4 VPermissible range, upper limit (DC) 28.8 VTimeClock switches● Number 400; Max. 400, depending on function● Power reserve 480 hDigital inputsNumber of inputs 8; of which 4 can be used as analogue (0 ... 10 V)Digital outputsNumber of outputs 4; transistorShort circuit protection Yes; electrical (1 A)Output current● for signal "1" permissible range for 0 ... 55 °C, max. 0.3 AEMCRadio interference emission according to EN 55 011● Limit value class B, for use in residentialareasYes; Radio interference suppression according to EN 55011, limit value class BStandards, approvals, certificatesCE marking YesCSA approval YesUL approval YesFM approval Yesdeveloped in accordance with IEC 61131 Yesaccording to VDE 0631 YesMarine approval YesAmbient conditionsAmbient temperature in operation● min. -20°C; without condensation● max. 55 °CAmbient temperature for storage/transport● min. -40 °C● max. 70 °C

Read more less

SIEMENS LOGO! 24RCE 6ED10521HB080BA1  LOGO! 24RCE, logic module, PS/I/O display: AC 24 V/DC 24 V/relay, 8 DI/4 DO, 400 block memory, Ethernet modularity and expandability, integrated Web Server, data log, custom web pages, card standard microSD for LOGO! Soft Comfort as of V8.3, previous projects executable, cloud connection in all LOGO! basic devices 8.3. DisplayWith display YesMounting typeMounting on 35 mm standard rail, width of 4 units dimensionSupply voltageRated value (DC)● DC 24 V YesPermitted range, lower limit (DC) 20.4 VPermissible range, upper limit (DC) 28.8 VRated value (AC)● AC 24 V YesMains frequency● Range allowed, lower limit 47 Hz● Allowed range, upper limit 63 HzTimeClocks switches● Number 400; Max. 400, depending on function● Power reserve 480 h Digital inputsNumber of inputs 8Digital outputsNumber of outputs 4; RelayShort circuit protection No; requires external protection Relay outputsContact breaking capacity— with inductive load, max. 3 A— with ohmic load, max. 10 AEMCRadio interference emission according to EN 55 011● Limit value class B, for use in zones residentialYes; Radio interference suppression according to EN 55011, limit value class BStandards, approvals, certificatesCE marking YesCSA approval YesUL approval YesApproval FM Yesdeveloped according to IEC 61131 Yesaccording to VDE 0631 YesMarine approval Yes

Read more less

SIEMENS LOGO! 12/24RCE 6ED10521MD080BA1 LOGO! 12/24RCE, logic module, display PS/I/O: 12/DC 24 V/relay, 8DI (4AI)/4DO, 400 block memory, Ethernet modularity and expandability, integrated Web Server, data log, customized web pages, standard microSD card for LOGO! Soft Comfort as of V8.3, previous projects executable, cloud connection in all LOGO! basic devices 8.3. DisplayWith display YesMounting typeMounting on 35 mm standard rail, width of 4 units dimensionSupply voltageRated value (DC)● 12 V DC Yes● 24 V DC YesPermitted range, lower limit (DC) 10.8 VAllowable range, upper limit (DC) 28.8 V TimeClock switches● Number 400; Max. 400, depending on function● Power reserve 480 hDigital inputsNumber of inputs 8; of which 4 can be used as analogue (0 ... 10 V)Digital outputsNumber of outputs 4; RelayShort circuit protection No; requires external protectionOutput current● for signal "1" permitted range for 0 ... 55 °C, max. 10 ARelay outputsContact breaking capacity— with inductive load, max. 3 A— with ohmic load, max. 10 AEMCRadio interference emission according to EN 55 011● Limit value class B, for use in residentialareasYes; Radio interference suppression according to EN 55011, limit value class BStandards, approvals, certificatesCE marking YesCSA approval YesUL approval YesApproval FM Yesdeveloped according to IEC 61131 Yesaccording to VDE 0631 YesMarine approval Yes
