SIEMENS PLC BASE UNIT (CPU MODULES)

SIEMENS SIMATIC S7-1500, CPU 1511-1 PN  6ES75111AK020AB0 SIMATIC S7-1500, CPU 1511-1 PN, Central processing unit with 150 KB work memory for program and 1 MByte for data, 1st interface: PROFINET IRT with 2-port switch, Bit performance of 60 NS, SIMATIC Memory Card required.    General informationProduct type designation CPU 1511-1 PNHardware version FS03Firmware version V2.9 Product function● I&M data Yes; I&M0 ... I&M3● Isochronous operation Yes; Decentrally and centrally; with min. OB 6 x cycle of 625 μs(decentrally) and 1 ms (centrally) Engineering with● STEP 7 TIA Portal configurable/integrated fromversionV17 (FW V2.9) / from V15 (FW V2.5 ); configurable as 6ES7511-1AK01-0AB0with older versions of TIA Portal Configuration controlvia data set Yes DisplayScreen diagonal [cm] 3.45 cmControl elementsNumber of keys 8Operating mode keys 2 Supply voltageRated value (DC) 24 VAllowable range, lower limit (DC) 19.2 VAllowable range, upper limit (DC) ) 28.8 VReverse polarity protection Yes Mains and voltage failure buffering● Mains/voltage failure buffering time 5 ms● Repetition rate, min. 1/s Input currentCurrent consumption (nominal value) 0.7 ACurrent consumption, max. 0.95 AInrush current, max. 1.9A; Nominal valueI²t 0.02 A²·s PowerSupply power in the backplane bus 10 WPower absorbed by the backplane bus (balanced) 5.5 W Power dissipationPower dissipation, typ. 5.7 W MemoryNumber of slots for SIMATIC Memory Card 1SIMATIC Memory Card required Yes

Read more less

Siemens 6ES75121CK004AB11512C-1 PN Compact CPU Training Package including: S7-1500 CPU 1512C-1 PN, 250 KB/1 MB, 32 DI, 32 DQ, 5 AI, 2 AQ , SIMATIC Memory Card 24 MB, incl. front connector, RJ45/RJ45 Ethernet cable 6m, profile rail, 482mm, PM 24V/8A, STEP 7 training software .

Read more less

Siemens 6ED10573SA200YA1 LOGO! 8 Schulungspaket 12/24RCE with 6 LOGO! 12/24RCE, 6 LOGO! DM8 12/24R, 6 LOGO! SOFT Comfort V8, Single License for 1 E-SW installation, SW and documentation on DVD, in 6 languages, runs on Windows XP, 7, 8, 10 MAC OS x 10.7 Lion up to and including Mac OSx El Capitan, Linux SUSE 11.3, SP3, K 3.0.76. reference hardware: LOGO! Use for educational purposes only.

Read more less

Siemens 6DL11936GA000NN0simatic et 200sp ha, support module 2x support for accommodating 2 I/O modules et 200sp ha

Read more less

Siemens 6ES71366BA000AB1 Safety training package for SIMATIC ET 200SP including: 1x F-DI 8x 24VDC HF, 1x F-DQ 4x 24VDC/2A PM HF, 1x F-RQ DC 24V /AC 24..230V/5A, 3x BaseUnits, labeling labels

Read more less

Siemens 6ES75163FN004AB2CPU 1516F-3 PN/DP training package comprising: S7-1500 CPU 1516F-3 PN/DP, 1.5 MByte/5 MByte, 32 DI, 32 DQ, 8 AI, 4 AQ, SIMATIC Memory Card 24 Mbyte, 4 40-pole front connectors RJ45/RJ45 Ethernet cable 6m profile rail, 482mm PM 24V/8A, STEP 7 training software.

Read more less

Siemens 6DL11936MD000AA0et 200sp ha, profile rail 1500 mm (approx. 59 inches) incl. Grounding screw, integrated profile rail for mounting small parts e.g. terminals, automatic switch and relay

Read more less

Siemens 6ES74162XP070AB0simatic s7-400, cpu 416-2, central unit with: 8 MB working memory, (4 MB codes, 4 MB data), 1st interf. mpi/dp 12 mbit/s, 2nd interf. profibus dp

Read more less

Siemens 6ES73172FK140AB0cpu simatic s7-300 317f-2 pn/dp, central unit with 1.5mb working memory, 1st interf. mpi/dp 12mbit/s, 2nd interf. Profinet Ethernet, with 2 port switches, micro memory card needed, powerful, compact and economical. simatic s7-300 allows space-saving modular assembly. the wide range of units can be used depending on the tasks for central expansions or for the creation of decentralized structures for economical management of spare parts. simatic is synonymous with continuity and quality. Do you want to continue using the investment in your machines and systems? even more power and performance for your machine? with the innovative simatic s7-1500 the successor to the simatic s7-300 is ready. this generation of controllers integrates brand new, future-proof technologies into the automation system, with improved system properties. together with the tia portal engineering system, the common engineering for all simatic controllers, we are best prepared to cope with increasingly rapid market changes, increasingly shorter product life cycles and growing competitiveness as well as to cost pressure. Product lifecycle information: The simatic s7-300 / et 200m system families, as part of our consolidated product programme, will be available in principle until 2023. when an end-of-life product declaration will be published series, the respective products will be available as spare parts for a further 10 years.

Read more less

Siemens 6ES75184AP000AB0simatic s7-1500, cpu 1518-4 pn/dp, central unit with work memory of 6 MB for the program and 60 MB for the data, 1st interface: profinet irt with 2-port switch, 2nd interface: profinet rt, 3rd interface: ethernet, 4th interface: profibus, 1 ns bit performance, simatic memory card required the simatic® s7-1500 advanced controller sets new standards of reference regarding system performance and usability. The direct integration of the S7-1500 controller into the Totally Integrated Automation Portal (TIA Portal) offers advantages such as common data management, a single operating concept and central services. this makes the use of functions extended to the entire system particularly simple. with its fast reaction times of the controller system it contributes to greater productivity. this means greater flexibility and a shorter time to bring products to market. for simatic s7-1500 several CPUs with diversified power are available in different performance classes. the portfolio includes on the one hand standard CPUs, partly with the possibility of integrating c/c++ code. Compact CPUs have integrated digital and analogue counting inputs and pulse outputs are available directly on the CPU. Using fail-safe CPUs, standard programs and safety programs can be executed on the same controller. the technological CPUs expand the motion control functions available in all simatic s7-1500 controllers in favor of sophisticated solutions. The simatic S7-1500 advanced controller is designed with the simatic step 7 professional software. A simatic memory card. is required for operation of this unit

Read more less

Siemens 6ES73125BF040AB0simatic s7-300, cpu 312c compact cpu with mpi, 10 di/6 do, 2 fast counters (10 khz) integrated 24 v dc power supply, working memory 64 kbyte, front connector (1 x 40 pole) and micro memory card required, powerful, compact and economical. simatic s7-300 allows space-saving modular assembly. the wide range of units can be used depending on the tasks for central expansions or for the creation of decentralized structures for economical management of spare parts. simatic is synonymous with continuity and quality. Do you want to continue using the investment in your machines and systems? even more power and performance for your machine? with the innovative simatic s7-1500 the successor to the simatic s7-300 is ready. this generation of controllers integrates brand new, future-proof technologies into the automation system, with improved system properties. together with the tia portal engineering system, the common engineering for all simatic controllers, we are best prepared to cope with increasingly rapid market changes, increasingly shorter product life cycles and growing competitiveness as well as cost pressure. Product lifecycle information: The simatic s7-300 / et 200m system families, as part of our consolidated product programme, will be available in principle until 2023. when an end-of-life product declaration will be published series, the respective products will be available as spare parts for a further 10 years.

Read more less

Siemens 6ES73121AE140AB0simatic s7-300, cpu 312 central unit with mpi, integrated 24 v dc power supply, 32 kbyte working memory, micro memory card required powerful, compact and economic. simatic s7-300 allows space-saving modular assembly. the wide range of units can be used depending on the tasks for central expansions or for the creation of decentralized structures for economical management of spare parts. simatic is synonymous with continuity and quality. Do you want to continue using the investment in your machines and systems? even more power and performance for your machine? with the innovative simatic s7-1500 the successor to the simatic s7-300 is ready. this generation of controllers integrates brand new, future-proof technologies into the automation system, with improved system properties. together with the tia portal engineering system, the common engineering for all simatic controllers, we are best prepared to cope with increasingly rapid market changes, increasingly shorter product life cycles and growing competitiveness as well as cost pressure. Product lifecycle information: The simatic s7-300 / et 200m system families, as part of our consolidated product programme, will be available in principle until 2023. when an end-of-life product declaration will be published series, the respective products will be available as spare parts for a further 10 years.

Read more less

Siemens 6ES72151HG400XB0simatic s7-1200, cpu 1215c, compact cpu, dc/dc/relay, 2 profinet ports, onboard i/o: 14 of dc 24 v, 10 of relay 2a, 2 ai 0-10v dc, 2 ao 0-20ma dc, power supply: dc 20.4-28.8v dc, program/data memory 125 kb simatic s7-1200 basic controller - flexibility guaranteed by various communication options. basic controllers are the best choice for flexibly and efficiently solving automation tasks in the medium-low performance range. the central units are scalable in their performance and are available for different input voltages and with transistor or relay outputs. safety variants are also available. In addition to the already integrated inputs and outputs, the compact CPUs can be expanded directly on the device or with different input/output and communication modules to adapt them perfectly to your needs. HMI devices can also be connected via the integrated Ethernet interface. The CPU memory can be expanded via memory card, the PLC is designed with the Step 7 Basic software in the TIA Portal. the micro-plc has multiple networking possibilities via different communication standards with integrated functions (profinet, modbus, etc.) or additional modules (io-link, as-i, etc.) and therefore offers maximum flexibility for configuring networks and topology. Thanks to its compact design, the fields of application for the S7-1200 are numerous and range from simple packaging machines to heating systems, right up to use as a subordinate system in large systems. compact design, modular structure and integrated I/Os save space in the control cabinet. the step7 planning software is integrated into the tia portal and thus accesses common data management, a uniform operating concept and homogeneous communication services for all components of a system. this means faster commissioning and reduced planning effort.

Read more less

Siemens 6AG13172FK142AB0siplus s7-300 cpu 317f-2pn/dp -25 ... +60 °c, with conformal coating based on 6es7317-2fk14-0ab0 . central unit with 1.5 MB working memory, 1st MPI/DP interface 12 Mbit/s, 2nd Profinet Ethernet interface, with 2-port switch, micro memory card required The SiPlus Extreme variant protects the automation components even from harsh environmental conditions which can occur especially with particularly high or low temperatures, harmful gases, condensation, frost and biologically, chemically and mechanically active substances, as happens in the case of electrical panels close to production or solutions installed in containers. Your medium to highly complex automation tasks are therefore reliably protected and offer additional investment security.

Read more less

Siemens 6AG13146CH047AB0siplus s7-300 cpu 314c-2dp for use in aggressive atmospheres -25 ... +70 °c, based on 6es7314-6ch04-0ab0. compact cpu with mpi, 24 di/16 do, 4ai, 2 ao, 1 pt100, 4 fast counters (60 khz), integrated dp interface, integrated 24 v dc power supply, 192 kbyte working memory, front connector (2x a 40 poles) and micro memory card required the siplus extreme variant protects the automation components even from harsh environmental conditions which can occur especially with particularly high or low temperatures, harmful gases, condensation, frost and biologically, chemically and mechanically active substances, such as it happens in the case of electrical panels close to production or solutions installed in containers. Your medium to highly complex automation tasks are therefore reliably protected and offer additional investment security.

Read more less

Siemens 6ES74122XK070AB0simatic s7-400, cpu 412-2 central unit with: working memory 1 mb, (0.5 mb codes 0.5 mb data) 1st interf. mpi/dp 12 mbit/s, 2nd interf. profibus dp.

Read more less

Siemens 6ES73152FJ140AB0cpu simatic s7-300 315f-2 pn/dp, central unit with 512 kbyte working memory, 1st interf. mpi/dp 12mbit/s, 2nd interf. Profinet Ethernet, with 2 port switches, micro memory card needed, powerful, compact and economical. simatic s7-300 allows space-saving modular assembly. the wide range of units can be used depending on the tasks for central expansions or for the creation of decentralized structures for economical management of spare parts. simatic is synonymous with continuity and quality. Do you want to continue using the investment in your machines and systems? even more power and performance for your machine? with the innovative simatic s7-1500 the successor to the simatic s7-300 is ready. this generation of controllers integrates brand new, future-proof technologies into the automation system, with improved system properties. together with the tia portal engineering system, the common engineering for all simatic controllers, we are best prepared to cope with increasingly rapid market changes, increasingly shorter product life cycles and growing competitiveness as well as cost pressure. Product lifecycle information: The simatic s7-300 / et 200m system families, as part of our consolidated product program, will be available in principle until 2023. when an end-of-life product declaration will be published series, the respective products will be available as spare parts for a further 10 years.

Read more less

Siemens 6ES73156FF040AB0simatic s7-300, cpu 315f-2dp fail-safe module with integrated mpi 24 V dc power supply, work memory 384 kb, width 40mm, 2nd interface . Master/Slave DP Micro Memory Card Required Powerful, Compact and Economical. simatic s7-300 allows space-saving modular assembly. the wide range of units can be used depending on the tasks for central expansions or for the creation of decentralized structures for economical management of spare parts. simatic is synonymous with continuity and quality. Do you want to continue using the investment in your machines and systems? even more power and performance for your machine? with the innovative simatic s7-1500 the successor to the simatic s7-300 is ready. this generation of controllers integrates brand new, future-proof technologies into the automation system, with improved system properties. together with the tia portal engineering system, the common engineering for all simatic controllers, we are best prepared to cope with increasingly rapid market changes, increasingly shorter product life cycles and growing competitiveness as well as cost pressure. Product lifecycle information: The simatic s7-300 / et 200m system families, as part of our consolidated product programme, will be available in principle until 2023. when an end-of-life product declaration will be published series, the respective products will be available as spare parts for a further 10 years.

Read more less

Siemens 6ES74105HX080AB0simatic pcs 7, cpu 410-5h process automation, central unit for s7-400 and s7-400h/f/fh, 5 interfaces: 2x pn, 1x dp, 2x per sync-module for use as a spare part, without system expansion card.

Read more less

Siemens 6ES71556AU000AB1Training package SIMATIC ET 200SP Energy Meter including: 1x IM155-6PN HF, 1x BusAdapter BA 2 x RJ45, 2x DI 8x 24VDC/0.5A HF, 2x DQ 8x 24VDC/0.5A HF, 1x AI Energy Meter ST, 5x BaseUnits, screen connections, labeling labels, color identification plates.

Read more less

Siemens 6ES74125HK060AB0simatic s7-400h, cpu 412-5h, central unit for s7-400 and s7-400f/fh, 5 interfaces: 1x mpi/dp,1x dp, 1x pn and 2 for sync-module, 1 MB memory (512 kb data/512 kb program).

Read more less

Siemens 6ED10573SA200YB1LOGO! 8 230RCE training pack with 6 LOGO! 230RCE, 6 LOGO! DM8 230R, 6 LOGO! SOFT Comfort V8, Single License for 1 E-SW installation, SW and documentation on DVD, in 6 languages ​​runs on Windows XP, 7, 8, 10 (32 and 64 bit), Mac OSx 10.7 Lion up to and including Mac OSx El Capitan , Linux SUSE 11.3, SP3, K 3.0.76, reference hardware: LOGO!

Read more less

Siemens 6ES72141HF400XB0simatic s7-1200, cpu 1214 fc, compact cpu, dc/dc/relay, onboard i/o: 14 of dc 24 v 10 of relay 2a 2 ai 0 -10v dc, power supply: dc 20.4-28.8v dc, program/data memory 125 kb simatic s7-1200 basic controller - flexibility guaranteed by various communication options. basic controllers are the best choice for flexibly and efficiently solving automation tasks in the medium-low performance range. the central units are scalable in their performance and are available for different input voltages and with transistor or relay outputs. safety variants are also available. In addition to the already integrated inputs and outputs, the compact CPUs can be expanded directly on the device or with different input/output and communication modules to adapt them perfectly to your needs. HMI devices can also be connected via the integrated Ethernet interface. The CPU memory can be expanded via memory card, the PLC is designed with the Step 7 Basic software in the TIA Portal. the micro-plc has multiple networking possibilities via different communication standards with integrated functions (profinet, modbus, etc.) or additional modules (io-link, as-i, etc.) and therefore offers maximum flexibility for configuring networks and topology. Thanks to its compact design, the fields of application for the S7-1200 are numerous and range from simple packaging machines to heating systems, right up to use as a subordinate system in large systems. compact design, modular structure and integrated I/Os save space in the control cabinet. the step7 planning software is integrated into the tia portal and thus accesses common data management, a uniform operating concept and homogeneous communication services for all components of a system. this means faster commissioning and reduced planning effort.

Read more less

Siemens 6AG14143EM077AB0siplus s7-400 cpu 414-3 pn/dp based on 6es7414-3em07-0ab0 with conformal coating, -25…+70°c, central unit with: working memory 4 MB, (2 MB code, 2 MB data), interfaces 1st interface mpi/dp 12 mbit/s (x1), 2nd interface ethernet/profinet (x5) 3rd interface if 964-dp pluggable (if1) the siplus extreme variant protects the automation components also from harsh environmental conditions that can occur especially with particularly high or low temperatures, harmful gases, condensation, frost and biologically, chemically and mechanically active substances, as happens in the case of electrical panels close to production or solutions installed in containers. Your highly complex automation tasks are therefore reliably protected and offer additional investment security.

Read more less
