ACCESSORIES AND SPARE PARTS FOR FREQUENCY CONVERTERS

Siemens 6SL32550AA004HA1handheld for Intelligent Operator Panel IOP-2 includes IOP-2, portable case power supply (International) rechargeable batteries (4xAA) RS-232 connection cable (3m) and cable USB (1m) note: KC certified note: KC certified Handheld for intelligent control panel for direct connection to the converter. SINAMICS Intelligent Operator Panel (IOP-2). Control, supervision, commissioning, diagnostics, local services A handheld version is available for direct and wired use of the Intelligent Operator Panel (IOP-2). This includes, in addition to the IOP-2, a case with batteries, charger and RS232 connection cable. With fully charged batteries the operating autonomy is approximately 8 hours. To connect the IOP-2 Handheld to the SINAMICS G110D, SINAMICS G120D, SINAMICS G110M or SINAMICS G120X, the RS232 connection cable with optical interface is also required. The IOP-2 is upgradeable and expandable via the integrated USB interface. You can transfer data from the PC to the IOP-2 to support future drive types. The USB interface also offers the ability to load additional languages ​​and wizards as they become available in the future, as well as perform firmware updates for the IOP-2. The charger is supplied with adapters for Europe, USA and UK. SINAMICS - the drive for me.

Read more less

Rockwell Automation 20-750-ENC-1Accessories and spare parts for Rockwell Automation frequency converter series/model POWERFLEX 750 ENCODER OPTION MODULE

Read more less

Eaton 186946Keyboard with LED display for DA1 and DC1 variable frequency drives.

Read more less

Lovato VLBXL03LOGICAL UNIT WITH PROFINET FOR VLB3...

Read more less

Siemens 6SL32550AA004JA2SINAMICS G Intelligent Operator Panel IOP-2 for SINAMICS G120, G120P G110M, G110D, G120D, G120C ET 200PRO FC-2 language support: German, English, French Italian, Spanish Portuguese, Dutch Swedish, Russian Czech, Polish Turkish, Finnish Chinese simplified environmental class during operation: chemically harmful substances class 3C3 according to IEC 60721-3-3: 2002 Intelligent control panel for direct connection to the converter. SINAMICS Intelligent Operator Panel (IOP-2). Local control, supervision, commissioning, diagnostics, service The flat IOP-2 Intelligent Operator Panel enables rapid local commissioning, error diagnostics and intuitive control of the SINAMICS G converter series, while at the same time facilitating Adaptation of settings during operation. The innovative centralized multifunction sensor control panel helps the user select settings. If you wish to use the IOP-2 there are three variants available: Direct connection to the control unit of the converter, door mounting for use outside the cabinet and the use of the IOP Handheld when control can only take place via cable in hard-to-reach places The IOP-2 is an additional option for the SINAMICS G120, G120C, G120P, G120X, G110D, G120D, G110M converter series, as well as for SIMATIC ET 200pro FC-2. SINAMICS - the drive for me.

Read more less

Siemens 6SL32550VA005AA0SINAMICS V20 Smart Access Web Server Module Web server-based control panel with wireless client connection SINAMICS V20 Smart Access Module for mobile commissioning, diagnostics, service. The optional SINAMICS V20 Smart Access Module can simply be inserted onto the inverter. Thanks to commissioning and control via smartphone, tablet or laptop, it also makes operating the SINAMICS V20 frequency inverter even easier and more convenient. SINAMICS - the drive for me.

Read more less

Schneider Electric VW3A1104R30Remote mounting cable with 2 RJ45 connectors

Read more less

Siemens 6SL32604NA001VB0 Prefabricated setpoint cable for connection to SINAMICS V90 with Controller 50x0.08 Tmax.= 13.7 mm Length (m)=1 m SINAMICS control/setpoint cable for the SINAMICS V90 frequency converter. The setpoint signal cable has a 50-pin plug connector at both ends and a separate terminal block on the controller side. The cable is available in lengths between 0.5 m and 1 m. SINAMICS - the drive for me.

Read more less

Siemens 6SL32550AA005AA0SINAMICS G120 Web Server Module Operating unit based on Web server with wireless client connection. SINAMICS G120 Smart Access Module.Mobile. Intelligent. Faster. The SINAMICS G120 Smart Access Module allows you to connect mobile devices (smartphones, tablets, laptops) via Wi-Fi with the SINAMICS G120, G120C, G120X and G120P converter series. The result is a powerful tool with numerous functions for wireless commissioning, diagnostics and service. The module is set up in a few steps. Thanks to the Web server function, it requires no installation or download of additional software. A normal web browser and a common operating system are sufficient. The user interface of the SINAMICS G120 Smart Access Module is structured and usable in a simple and intuitive way. The Smart Access Module is available as an additional option for the converter series SINAMICS G120C, SINAMICS G120X, SINAMICS G120 with Control Unit CU230P-2 or CU240E-2 as well as SINAMICS G120P with CU230P-2. SINAMICS - the drive for me.

Read more less

Siemens 6SL32550VA004BA1SINAMICS V20 BOP dimensions: 76x85x30 (WxHxD) Basic control panel for direct connection SINAMICS Basic Operator Panel (BOP) for SINAMICS V20. Local control, supervision, commissioning, diagnostics Navigating the menus of the Basic Operator Panel BOP facilitates local commissioning of the SINAMICS V20 converter. SINAMICS - the drive for me.

Read more less

Schneider Electric VW3A8306D30The RS 485 cable set allows the integration of the product into the serial Modbus connection. It has a length of 3 m. It is equipped with 1 RJ45 and free wires at the other end.

Read more less

Siemens 6SL32030BB218VA1SINAMICS V90/S210 Line Filter category C2 for 1 AC 200 ... 240V, 18 A dimension 62x155x53 (WxHxD)

Read more less

Lovato VLBXP01Hatch mounting kit

Read more less

Omron AXFIC4017SE

Read more less

Siemens 6SL32560AP000JA0door mounting set SINAMICS G120 IP55/ UL type 12 intelligent Operator Panel IOP (IP54), IOP-2 (IP55) and Basic Operator Panel BOP-2 (IP55) includes material seal fastening and connecting cable (5m) SINAMICS door mounting kit Door mounting kit for Intelligent Operator Panel (IOP-2) and Basic Operator Panel (BOP-2) for the SINAMICS G120 modular frequency converter and the SINAMICS G120C compact converter. With an optional door mounting kit, an operator panel can be installed on an electrical panel door quickly and easily. When mounted in a door, the Intelligent Operator Panel (IOP-2) achieves the degree of protection IP55/UL Type 12 and the Basic Operator Panel (BOP-2) achieves the degree of protection IP55. The following are included in the scope of delivery: the gasket, the fixing material and a 5 m long connection cable. SINAMICS - the homogeneous drive family for every field of application.

Read more less

Siemens 6SL32550VA002AA1SINAMICS V20 BOP interface dimensions: 49x56x23 (WxHxD) Interface for Basic Operator Panel SINAMICS BOP interface for SINAMICS V20. The BOP interface represents the connection between the SINAMICS V20 converter and the BOP (Basic Operator Panel). The RJ45 interface is compatible with standard network cables. SINAMICS - the drive for me.

Read more less

Siemens 6SL32550AA004CA1SINAMICS G120 Basic Operator Panel (BOP-2) Basic control panel for direct connection to the SINAMICS Basic Operator Panel (BOP-2). Local control, supervision, commissioning, diagnostics The menu navigation and 2-line display of the Basic Operator Panel BOP-2 facilitates local commissioning of the SINAMICS G120, G120C, G120P and G120X converter series. The simultaneous representation of the parameter and its value, as well as the possibility of filtering the parameters, facilitate the commissioning of a drive and in most cases allow it to be carried out without having to have a printout of the parameterization list. The BOP-2 is available as an option for the SINAMICS G120 converter series with Control Unit CU240B/E-2 or CU250S-2, SINAMICS G120P with Control Unit CU230P, SINAMICS G120X and SINAMICS G120C. SINAMICS - the drive for me.

Read more less

Schneider Electric SZ1RV1202The potentiometer replaces the speed variator. It is compatible with all Altivar ranges. Its internal conversion resistance is 2.2 kOhm and has a protection index of IP20.

Read more less

Lovato VLBX C01DISPLAY AND KEYBOARD FOR VLB3...

Read more less

Pepperl+Fuchs Hart Loop Converter KFD2-HLC-Ex1.D  261916  Technical data General specificationsSignal type Analog inputReplenishConnection Power rail or terminals 23+, 24-Rated voltage Ur 19 ... 30 V DCRated current Ir approx. 120 mA at 24 V DCPower dissipation 2.3 WPower consumption 2.9 WHART signal channels (intrinsically safe)HART field device input (revision 5 to 7)

Read more less

ALLEN-BRADLEY 2198P070 Accessories and spare parts for Rockwell Automation frequency converter series/model KINETIX 5700 DC BUS SUPPLY  ConstructionHeight 358 mmWidth 55 mmDepth 250 mmElectricalControl power DC input current 0.8 AInternal shunt power 75 W Capacitive power consumption 172 JInternal shunt resistance 37.5 OhmInternal capacitance 780 µFRated output power 151 W at 100%DC output continuous current to bus 25.5 A, 3-phasePeak bus output current 70.3 A, 3-phaseMain AC input current 27.0 A at 324...524 V rms, 3-phasePeak AC input current 74.3 A at 324...524 V rms, three phaseControl supply current 4 A at 24 V inrush currentContinuous output power to bus 8.5 kW at 240 V rms nominal, three-phase at 1/2 power, 17.0 kW at 480 V rms nominal, three-phase.Peak output power to the bus 23 kW at 240 V rms nominal, three-phase at 1/2 power, 46 kW at 480 V rms nominal, three phase.Line loss for 20 msEfficiency 99%AC input frequency 47 HzControl power DC input voltage 24 V DC (±10%)Voltage bus output nominal 458...747 V DCInrush, max 33 A (zero to peak)Bus surge voltage 832 V DC to 480 V, AC input nominalAC input voltage 195.. .528V rms 3-phase (240/480V nom)Shunt on 775V plus 30V x bus regulator capacity/usageShunt 765V plus 30V x bus regulator capacity/usageMechanicalWeight 4.42 kg

Read more less

ALLEN-BRADLEY Accessories and spare parts for Rockwell Automation frequency converter series/model POWERFLEX ARCHITECTURE CLASS HIM 20HIMA6   ConverterProtocol: DPIData rate: 125 kbps or 500 kbps ConsumptionConverter (DPI): 140 mA at 12 V DC supplied by the host drive Dimensions - H x W x D116 x 70 x 16 mmWeight 91 g TemperatureOperation: 0...50 °CStorage: -40...85 °CRelative humidity: 5...95% non-condensing Atmosphere: Important: The module should not be installed in an area where the ambient atmosphere contains volatile or corrosive gases, vapors, or dust.If the module is not to be installed immediately, should be stored in an area where it will not be exposed to a corrosive atmosphere. UV radiation: The operator interface module is not guaranteed against UV radiation. VibrationsIn operation: 2.5 G at 5...2,000 HzAt rest: 5 G at 5...2,000 HzShocksIn operation: Peak acceleration 30 G, 11 (±1) ms pulse widthAt rest: Peak acceleration 50 G, 11 (±1) ms pulse width

Read more less

SIEMENS SINAMICS S120 6SL30550AA004BA0 Control element with 2-line BOP 20 miniature display, 6 keys for parameterization and diagnostics. suitable for control units CU305, CU310, CU320.

Read more less
