Description
SIMATIC ET 200SP 6ES71316BF000CA0
Digital input module, DI 8x DC 24V High Feature, Input type 3 (IEC 61131), Sink Input, (PNP, read on P), Packaging unit: 1 piece suitable for BU type A0, Color code CC01 , Input delay 0.05..20ms; Channel diagnostics for: short circuit in encoder supply, wire break, supply voltage, channel error LED .
General information
Product type designation: DI 8x24 VDC HF
Hardware version: From FS07
Possible FW update: Yes
Usable BaseUnits: BU type A0
Color code for module-specific color coding label:CC01
Supply voltage
Rated value (DC): 24 V
Allowable range, lower limit (DC): 19.2 V
Allowable range, upper limit (DC): 28.8 V
Reverse polarity protection : Yes
Power dissipated
Power dissipation, typ.: 1.5 W; 24 V, 8 inputs powered by transducer power supply
