TM5SAI2L |Schneider Electric

Description

Description

Schneider Electric TM5SAI2L

Analog input module 2 inputs, +/-10 V / 0...20mA / 4...20mA, 12 bits. Product range: Modicon TM5 - Product or component type: Analog input module - Analog input type: Current 0...20 mA/4...20 mA, differential, Voltage +/- 10 V, differential - Analog input resolution: 12 bits + sign +/- 10 V, 12 bits 0...20 mA/4...20 mA.

Technical data
 Range compatibility
Modicon M258
Modicon LMC058
Product Compatibility
Logic controller
Motion controller
resolution measure
2.441mV, +/- 10V
4.883 µA, 0...20 mA/4...20 mA
Color
White
input impedance
>= 20 mOhm voltage
ohmic load impedance
<= 300 Ohm (current)
sampling duration
1 ms, analog input type: all inputs with filtering
300 µs, analog input type: all inputs without filtering
measurement error
< 0.08% of full scale +/- 10 V +/- 10 V at 25 °C
< 0.08% of full scale 0...20 mA/4...20 mA at 25 °C
temperature coefficient
+/- 0.009 %FS/°C, analog input type: current
+/- 0.006 %FS/°C, analog input type: voltage
non-linearity
< 0.025%FS, analog input type: voltage
< 0.05%FS, analog input type: current
Type of cables
Shielded cable
insulation
No insulation between channels
500 Vrms AC isolation between channel and bus
Diet
Internal
Rated supply voltage [Us]
24V DC -15...20%
Common mode rejection
> 70dB
local reporting
1 green LED for power
1 red LED for power
2 green LEDs for input status
current absorption
2 mA at 5 V DC bus
33 mA at 24 V DC input/output
Maximum power dissipation in W
0.81W
Marking
THERE IS
Net weight
0.025 kg

TM5SAI2L |Schneider Electric

Product form

SKU: TM5SAI2L
Barcode: 3595864074719

€305,38

  •  On order - Delivery in 2-6 weeks
  • HS CODE: 85371091
  • STANDARD RETURN
  • QUICK DELIVERY ASSURED
  DELIVERY TIMES

The delivery times for goods in the “AVAILABLE” status are usually 1 to 3 working days: the products are available in our main warehouse, ready for delivery for the quantity indicated, and the times required are those of shipping via express carrier and vary according to the destination.

The delivery times for goods in the “AVAILABLE EU WAREHOUSE” status are usually 3 to 5 working days and subject to unforeseeable variations.

The delivery times for goods in the “MADE TO ORDER” status are usually 2-6 weeks: contact our sales team for a precise indication
