Terminals for the distribution and distribution of power inside electrical panels and cabinets.
Features:
- Rated current: 80, 125, 175, 250 or 400 A
- Available with 7, 8 or 12 connections (depending on the types)
- Single pole or for multiple installations
- Cable connection capacity up to sections of 185 mm2
- Screw terminals
- Mounting on 35 mm rail (EN60715)
INPUT CABLES characteristics:
Number of inputs 3 1 2 1 1
Diameter of terminals Ømm 6.6 9.8 11.8 15.3 15.3
Minimum cable size
mm2 2.5 10 10 35 95
AWG 14 8 6 2 3/0
Maximum cable size
mm2 16 35 70 120 185
AWG 6 2 2/0 250 Kcmil 400 Kcmil
Strip length of cable cable
mm 15 15 15 28 28
Tightening tool Flat screwdriver Allen key Allen key Allen key Allen key
Tightening tool dimensions
mm 5.5/PZ2 4 5 6 8
Tightening torque Nm 1.5…2 3.5…5 6…10 19…21 2
Output cable characteristics:
Number of outputs 4 1 6 10 2 5 4 2 5 4
Diameter of terminals Ømm 4.5 6.8 6.4 6.4 8.7 6.4 5.7 8.7 6.4 5.7 Minimum cable size
mm2 2.5 6 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5
AWG 14 10 14 14 14 14 14 14 14 14
Maximum cable size
mm2 6 16 16 16 35 16 10 35 16 10
AWG 10 6 6 6 2 6 8 2 6 8
Cable stripping length
mm 11 11 11 11 11
Tightening tool Flat screwdriver
Allen wrenchFlat screwdriver
Flat screwdriver Allen key Allen key
Tightening tool dimensions
mm 4/PZ1 3 5.5 PZ2 5.5/PZ2 4 3 3 4 3 3
Tightening torque Nm 0.8…12 2…3 2…3 2…3 3.5…5 2…3 2…3 3.5…5 2…3 2…3
