6GK75426UX000XE0 | Siemens communication processor CP 1542SP-1

Description

Description

SIEMENS COMMUNICATION PROCESSOR CP
1542SP-1 6GK7542-6UX00-0XE0

CP 1542SP-1 communications processor for connecting a SIMATIC S7-ET 200SP module to Industrial Ethernet; open IE communication (TCP/IP, ISO on TCP, UDP), PG/OP, S7 routing, IP broadcast/multicast, SNMPV1, DHCP, e-mail, IPV4/IPV6, time synchronization via NTP, access to the company's web server CPU, BusAdapter required.

General information:

Baud rate
Baud rate
● on interface 1 10 ... 100 Mbit/s
interfaces
number of interfaces / according to Industrial Ethernet 1
number of electrical connections
● on interface 1 / second Industrial Ethernet 2
establishment of electrical connection
● on interface 1 / second Industrial Ethernet via ET 200SP BusAdapter (RJ45, FC, LC, SCRJ), integrated switch


Supply voltage
current absorbed, power dissipated
type of voltage / of the supply voltage DC
supply voltage 24 V
supply voltage 19.2 . .. 28.8 V
power dissipated [W] 6 W
ambient conditions
ambient temperature
● for vertical installation / during operation -30 ... +50 °C
● with horizontal installation / during operation -30 ... +60 °C
● during storage -40 ... +70 °C
● during transport -40 ... +70 °C


Relative humidity
● at 25 °C / non-condensing / during operation / max. 95 %
IP protection degree IP20


Constructive form, dimensions and weights
width 60 mm
height 117 mm
depth 74 mm
net weight 0.18 kg
type of fastening
● mounting on 35 mm DIN rail Yes
product features, product functions, product components / generic
number of units
● per CPU / max. 2
● note 2 CPs can be inserted for each CPU, simultaneous operation possible
with BA Send and CM DP
power data / open communication
number of connections possible / for open communication
● via T blocks / max. 32 volumes of data.

6GK75426UX000XE0 | Siemens communication processor CP 1542SP-1

Product form

SKU: 6GK7542-6UX00-0XE0
Barcode: 4047622199619

1 EU Warehouse Available

€418,69

    Free pickup in our shop(s)
    • HS CODE: 85176200
    • STANDARD RETURN
    • QUICK DELIVERY ASSURED
      DELIVERY TIMES

    The delivery times for goods in the “AVAILABLE” status are usually 1 to 3 working days: the products are available in our main warehouse, ready for delivery for the quantity indicated, and the times required are those of shipping via express carrier and vary according to the destination.

    The delivery times for goods in the “AVAILABLE EU WAREHOUSE” status are usually 3 to 5 working days and subject to unforeseeable variations.

    The delivery times for goods in the “MADE TO ORDER” status are usually 2-6 weeks: contact our sales team for a precise indication
